| ●材料：采用UL认可的尼龙材料 ●密封盖：丁晴橡胶(NBR), 耐候橡胶(EPDM) ●工作温度：静态-40℃至100℃ 或瞬间可耐热至120℃ 动态-20℃至80℃ 或瞬间可耐热至100℃ ●防护等级：IP68 ●颜色种类：灰色,黑色,其它颜色可定做 |
●Material: PA (NYLON), UL 94 ●Hermetic seal: NBR, EPDM ●Working temperature: -40℃ to 100℃ in static state Instantaneous heat resistance up to 120℃ -20℃ to 80℃ in dynamic state Instantaneous heat resistance up to 100℃ ●Degree of Protection: IP68 ●Color: Grey, Black, other colors customized. |
| Thread |  mm |
H mm |
GL mm |
d mm |
 mm |
| 3/8″NPT | 4-8 | 63 | 15 | 8,5 | 22/19 |
| 3/8″NPT | 2-6 | 63 | 15 | 8,5 | 22/19 |
| 1/2″NPT | 6-12 | 90 | 13 | 13 | 24 |
| 1/2″NPT | 5-9 | 90 | 13 | 13 | 24 |
| 1/2″NPT | 10-14 | 100 | 13 | 15,5 | 27 |
| 1/2″NPT | 7-12 | 100 | 13 | 15,5 | 27 |
| 3/4″NPT | 13-18 | 114 | 14 | 20 | 33 |
| 3/4″NPT | 9-16 | 114 | 14 | 20 | 33 |
