| ●材料：采用UL认可的尼龙材料 ●密封盖：丁晴橡胶(NBR), 耐候橡胶(EPDM) ●工作温度：静态-40℃至100℃ 或瞬间可耐热至120℃ 动态-20℃至80℃ 或瞬间可耐热至100℃ ●防护等级：IP68 ●颜色种类：灰色,黑色,其它颜色可定做 |
●Material: PA (NYLON), UL 94 ●Hermetic seal: NBR, EPDM ●Working temperature: -40℃ to 100℃ in static state Instantaneous heat resistance up to 120℃ -20℃ to 80℃ in dynamic state Instantaneous heat resistance up to 100℃ ●Degree of Protection: IP68 ●Color: Grey, Black, other colors customized. |
| Thread |  mm |
H mm |
GL mm |
d mm |
 mm |
| PG 7 | 3-6,5 | 54 | 8 | 7 | 15 |
| PG 7 | 2-5 | 54 | 8 | 7 | 15 |
| PG 9 | 4-8 | 63 | 8 | 8,5 | 19 |
| PG 9 | 2-6 | 63 | 8 | 8,5 | 19 |
| PG 11 | 5-10 | 78 | 8 | 10,5 | 22 |
| PG 11 | 3-7 | 78 | 8 | 10,5 | 22 |
| PG 13,5 | 6-12 | 90 | 9 | 13 | 24 |
| PG 13,5 | 5-9 | 90 | 9 | 13 | 24 |
| PG 16 | 10-14 | 100 | 10 | 15,5 | 27 |
| PG 16 | 7-12 | 100 | 10 | 15,5 | 27 |
| PG 21 | 13-18 | 114 | 11 | 20 | 33 |
| PG 21 | 9-16 | 114 | 11 | 20 | 33 |
| PG 7 | 3-6,5 | 54 | 15 | 7 | 15 |
| PG 7 | 2-5 | 54 | 15 | 7 | 15 |
| PG 9 | 4-8 | 63 | 15 | 8,5 | 19 |
| PG 9 | 2-6 | 63 | 15 | 8,5 | 19 |
| PG 11 | 5-10 | 78 | 15 | 10,5 | 22 |
| PG 11 | 3-7 | 78 | 15 | 10,5 | 22 |
| PG 13,5 | 6-12 | 90 | 15 | 13 | 24 |
| PG 13,5 | 5-9 | 90 | 15 | 13 | 24 |
| PG 16 | 10-14 | 100 | 15 | 15,5 | 27 |
| PG 16 | 7-12 | 100 | 15 | 15,5 | 27 |
| PG 21 | 13-18 | 114 | 15 | 20 | 33 |
| PG 21 | 9-16 | 114 | 15 | 20 | 33 |
