●材料：采用不锈钢201、304、316材质，各种长度皆可制作，特殊规格按客户供样制作；
●特性：耐酸、耐腐蚀、抗张强度高，使用简单，快捷等优势；
●工作温度范围：-60℃~150℃。
●All length are available, Stainless steel type: 201, 304, 316, Special sizes can be customized;
●Characteristic: They have an unique ball locking mechanism that allow easily and quickly installed and not undone, High tensile strength; Non-flammability High resistance to acetic acid, alkali acid, sulphuric acid. corrode ...etc;
●Working temperature: -60℃~150℃
| 规格型号 Part No. |
长度 Approx. Length mm(inch) |
宽度 Approx. Width mm(inch) |
捆绑直径 Max. Bundle Dia. mm(inch) |
拉力 Min. loop Tensile Strength N(lbs) |
| JSC-4.6×150 | 150(5.9) | 4.6(0.181) | 37(1.46) | 600(135) |
| JSC-4.6×200 | 200(7.87) | 50(1.97) | ||
| JSC-4.6×250 | 250(9.84) | 63(2.48) | ||
| JSC-4.6×300 | 300(11.8) | 76(2.99) | ||
| JSC-4.6×350 | 350(13.78) | 89(3.5) | ||
| JSC-4.6×400 | 400(15.75) | 102(4.02) | ||
| JSC-4.6×450 | 450(17.72) | 115(4.53) | ||
| JSC-4.6×500 | 500(19.69) | 128(5.04) | ||
| JSC-4.6×550 | 550(21.65) | 141(5.55) | ||
| JSC-4.6×600 | 600(23.62) | 154(6.06) | ||
| JSC-7.9×150 | 150(5.9) | 7.9(0.311) | 37(1.46) | 800(180) |
| JSC-7.9×200 | 200(7.87) | 50(1.97) | ||
| JSC-7.9×250 | 250(9.84) | 63(2.48) | ||
| JSC-7.9×300 | 300(11.8) | 76(2.99) | ||
| JSC-7.9×350 | 350(13.78) | 89(3.5) | ||
| JSC-7.9×400 | 400(15.75) | 102(4.02) | ||
| JSC-7.9×450 | 450(17.72) | 115(4.53) | ||
| JSC-7.9×500 | 500(19.69) | 128(5.04) | ||
| JSC-7.9×550 | 550(21.65) | 141(5.55) | ||
| JSC-7.9×600 | 600(23.62) | 154(6.06) | ||
| JSC-7.9×650 | 650(25.59) | 167(6.57) | ||
| JSC-7.9×700 | 700(27.56) | 180(7.09) | ||
| JSC-7.9×750 | 750(29.53) | 191(7.52) | ||
| JSC-7.9×800 | 800(31.5) | 193(7.59) |
