导线范围 Size of cable: 0.5~1.5mm2(A.W.G 22~16)
最大电流 Max. Current=10A
| 型号 Item No . |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||||
| W | W1 | L | F | F1 | E | D | d | |||
| PBDD 1.25-250 | 0.40 | 7.4 | 6.3 | 21.5 | 7.9 | 8.0 | 10.0 | 2.7 | 1.7 | 红Red |
| 导线范围 Size of cable: 1.5~2.5mm2(A.W.G 16~14) 最大电流 Max. Current=15A |
||||||||||
| PBDD2-250 | 0.40 | 7.4 | 6.3 | 21.5 | 7.9 | 8.0 | 10.0 | 3.3 | 2.3 | 蓝Blue |
| 导线范围 Size of cable: 4~6mm2(A.W.G 12~10) 最大电流 Max. Current=24A |
||||||||||
| PBDD 1.25-250 | 0.40 | 7.4 | 6.3 | 21.5 | 7.9 | 8.0 | 14 | 4.5 | 3.4 | 黄Yellow |
