导线范围 Size of cable: 0.5~1.5mm2(A.W.G 22~16)
最大电流 Max. Current=10A
| 型号 Item No . |
插接规格 NEMA Tab |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||
| B | L | F | H | D | d | ||||
| FDD 1.25-110(5) | 0.5×2.8 | 0.30 | 3.8 | 19.0 | 6.4 | 10.0 | 3.8 | 1.7 | 红Red |
| FDD 1.25-110(8) | 0.8×2.8 | 0.30 | 3.8 | 19.0 | 6.4 | ||||
| FDD 1.25-187(5) | 0.5×4.75 | 0.35 | 5.6 | 19.0 | 6.5 | ||||
| FDD 1.25-187(8) | 0.8×4.75 | 0.35 | 5.6 | 19.0 | 6.5 | ||||
| FDD 1.25-250 | 0.8×6.35 | 0.4 | 7.4 | 21.0 | 7.9 | ||||
导线范围 Size of cable: 1.5~2.5mm2(A.W.G 16~14)
最大电流 Max. Current=15A
| 型号 Item No . |
插接规格 NEMA Tab |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||
| B | L | F | H | D | d | ||||
| FDD 2-110(5) | 0.5×2.8 | 0.30 | 3.8 | 19.0 | 6.4 | 10.0 | 3.8 | 1.7 | 蓝Blue |
| FDD 2-110(8) | 0.8×2.8 | 0.30 | 3.8 | 19.0 | 6.4 | ||||
| FDD 2-187(5) | 0.5×4.75 | 0.35 | 5.6 | 19.0 | 6.5 | ||||
| FDD 2-187(8) | 0.8×4.75 | 0.35 | 5.6 | 19.0 | 6.5 | ||||
| FDD 2-250 | 0.8×6.35 | 0.4 | 7.4 | 21.0 | 7.9 | ||||
导线范围 Size of cable: 4~6mm2(A.W.G 12~10)
最大电流 Max. Current=24A
| 型号 Item No . |
插接规格 NEMA Tab |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||
| B | L | F | H | D | d | ||||
| FDD 5.5-250 | 0.8×6.35 | 0.40 | 7.4 | 25.0 | 7.9 | 12.5 | 5.7 | 3.4 | 黄Yellow |
