| ●材料：镀镍黄铜 ●固定连接组件：采用UL认可的尼龙材料 ●密封盖：丁晴橡胶(NBR), 耐候橡胶(EPDM) ●防护等级：IP68-10 ●工作温度：-40℃至100℃ 或瞬间可耐热至120℃ |
●Material: Nickel-plated brass ●Fixture pack: PA (NYLON), UL 94 ●Hermetic seal: NBR, EPDM ●Protection degree: IP68-10 ●Working temperature: -40℃ to 100℃ Instantaneous heat resistance up to 120℃ |
| Thread |  mm |
H mm |
GL mm |
 mm |
| PG 7 | 3-6,5 | 19 | 5 | 14 |
| PG 7 | 2-5 | 19 | 5 | 14 |
| PG 9 | 4-8 | 21 | 6 | 17 |
| PG 9 | 2-6 | 21 | 6 | 17 |
| PG 11 | 5-10 | 22 | 6 | 20 |
| PG 11 | 3-7 | 22 | 6 | 20 |
| PG 13,5 | 6-12 | 24 | 6,5 | 22 |
| PG 13,5 | 5-9 | 24 | 6,5 | 22 |
| PG 16 | 10-14 | 23 | 6,5 | 24 |
| PG 16 | 7-12 | 23 | 6,5 | 24 |
| PG 21 | 13-18 | 24 | 7 | 30 |
| PG 21 | 9-16 | 24 | 7 | 30 |
| PG 29 | 18-25 | 29 | 8 | 40 |
| PG 29 | 13-20 | 29 | 8 | 40 |
| PG 36 | 22-32 | 35 | 8 | 50 |
| PG 36 | 20-26 | 35 | 8 | 50 |
| PG 42 | 32-38 | 37 | 9 | 57 |
| PG 42 | 25-31 | 37 | 9 | 57 |
| PG 48 | 37-44 | 38 | 10 | 64 |
| PG 48 | 29-35 | 38 | 10 | 64 |
