导线范围 Size of cable: 0.5~1.5mm2(A.W.G 22~16)
最大电流 Max. Current=10A
| 型号 Item No . |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||
| bØ | F | DØ | dØ | F | L | |||
| FRD 1.25-156 | 0.4 | 4.0 | 16.0 | 2.7 | 1.7 | 13.0 | 24.5 | 红Red |
导线范围 Size of cable: 1.5~2.5mm2(A.W.G 16~14)
最大电流 Max. Current=15A
| 型号 Item No . |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||
| bØ | F | DØ | dØ | F | L | |||
| FRD 2-156 | 0.4 | 4.0 | 6.3 | 3.3 | 2.3 | 14.0 | 24.5 | 蓝Blue |
| FRD 2-195 | 0.4 | 5.0 | 7.0 | 3.3 | 2.3 | 14.0 | 24.5 | |
导线范围 Size of cable: 4~6mm2(A.W.G 12~10)
最大电流 Max. Current=24A
| 型号 Item No . |
材质厚度 Thickness Of Material (mm) |
尺寸 Dimension (mm) | 颜色 Color |
|||||
| bØ | F | DØ | dØ | F | L | |||
| FRD 5.5-195 | 0.4 | 5.0 | 7.0 | 4.5 | 3.4 | 14 | 29.5 | 黄Yellow |
