●材料：铁，SUS201，SUS304，SUS316
●表面处理：镀锌，不锈钢抛光
●温度范围：-40℃〜+120℃
●特性：橡胶具有耐老化性，耐腐蚀性；用于固定软管，钢管，电线电缆
注：其他规格可定做
●Material: Iron, SUS201, SUS304, SUS316
●Surface Treatment: Galvanized Iron, Polished stainless steel
●Temperature Range: -40℃~+120℃
●Property: The rubber has aging resistance, corrosion resistance
●Fixed the hose, steel tube, wire and cable
Note: other specifications can be customized
| 型号 ITEM No. | 规格 Spec. |
安装螺栓 Mounting screw |
宽度 (mm) |
厚度 Thickness (mm) |
包装 Package ( PCS/ Bag) |
|
| U shape | R shape | |||||
| PCU008 | PCR008 | 8 | M6 | 15.0 | 1.0 | 100 |
| PCU010 | PCR010 | 10 | M6 | 15.0 | 1.0 | 100 |
| PCU012 | PCR012 | 12 | M6 | 15.0 | 1.0 | 100 |
| PCU014 | PCR014 | 14 | M6 | 15.0 | 1.0 | 100 |
| PCU016 | PCR016 | 16 | M6 | 15.0 | 1.0 | 100 |
| PCU018 | PCR018 | 18 | M6 | 15.0 | 1.0 | 100 |
| PCU020 | PCR020 | 20 | M6 | 15.0 | 1.0 | 100 |
| PCU022 | PCR022 | 22 | M6 | 15.0 | 1.0 | 100 |
| PCU024 | PCR024 | 24 | M6 | 15.0 | 1.0 | 100 |
| PCU026 | PCR026 | 26 | M6 | 15.0 | 1.0 | 100 |
| PCU028 | PCR028 | 28 | M6 | 15.0 | 1.0 | 100 |
| PCU030 | PCR030 | 30 | M6 | 15.0 | 1.0 | 50 |
| PCU034 | PCR034 | 34 | M6 | 15.0 | 1.0 | 50 |
| PCU040 | PCR040 | 40 | M6 | 15.0 | 1.0 | 50 |
| PCU042 | PCR042 | 42 | M6 | 15.0 | 1.0 | 50 |
| PCU046 | PCR046 | 46 | M6 | 15.0 | 1.0 | 50 |
| PCU048 | PCR048 | 48 | M6 | 15.0 | 1.0 | 50 |
| PCU054 | PCR054 | 54 | M6 | 15.0 | 1.0 | 50 |
| PCU060 | PCR060 | 60 | M6 | 15.0 | 1.0 | 50 |
