●材质：采用UL认可之尼龙66料制成，防火等级94V-2， 耐酸、耐蚀、绝缘性良好，不易老化、承受力强。
●颜色：标准颜色为本色(白色)，另有抗外紫外线之黑色，特殊颜色欢迎订做。
●Material: Nylon 66, 94V-2 certificated by UL. Heat-resisting, erosion control, insulate well and not apt to age.
●Color: Natural(or white, standard color), UV black and other colors are available as requested.
| 型号 Item No . |
长L | 宽W (mm) |
捆扎范围 Bundle Diameter(mm) |
E | 承受力 Tensile Strength | ||
| Inch | mm | LBS | KGS | ||||
| JS-2.5×60 | 2.4" | 60 | 2.5 | 2-11 | 18 | 8 | |
| JS-2.5×80 | 3.2" | 80 | 2-16 | ||||
| JS-2.5×100 | 4.0" | 100 | 2-22 | ||||
| JS-2.5×120 | 4.7" | 120 | 2-30 | ||||
| JS-2.5×150 | 6.0" | 50 | 2-35 | ||||
| JS-2.5×160 | 6.3" | 160 | 2-40 | ||||
| JS-2.5×200 | 8.0" | 200 | 3-50 | ||||
| JS-3.5×150 | 6.0" | 150 | 3.5 | 3-35 | 40 | 18 | |
| JS-3.5×180 | 7.1" | 180 | 3-42 | ||||
| JS-3.5×200 | 8.0" | 200 | 3-50 | ||||
| JS-3.5×250 | 10" | 250 | 3-65 | ||||
| JS-3.5×280 | 11" | 280 | 3-70 | ||||
| JS-3.5×300 | 12" | 300 | 3-80 | ||||
| JS-3.5×370 | 14.6" | 370 | 3-105 | ||||
| JS-4.8×120 | 4.7" | 120 | 4.8 | 3-30 | 50 | 22 | |
| JS-4.8×160 | 6.3" | 160 | 3-40 | ||||
| JS-4.8×180 | 7.1" | 180 | 3-42 | ||||
| JS-4.8×200 | 8.0" | 200 | 3-50 | ||||
| JS-4.8×250 | 10" | 250 | 3-60 | ||||
| JS-4.8×280 | 11" | 280 | 3-70 | ||||
| JS-4.8×300 | 12" | 300 | 3-80 | ||||
| JS-4.8×350 | 14" | 350 | 3-90 | ||||
| JS-4.8×370 | 14.6" | 370 | 3-98 | ||||
| JS-4.8×400 | 16" | 400 | 3-105 | ||||
| JS-4.8×430 | 16.9" | 430 | 3-120 | ||||
| JS-4.8×450 | 17.7" | 450 | 3-130 | ||||
| JS-4.8×500 | 19.7" | 500 | 3-150 | ||||
| JS-7.2×150 | 6.0" | 150 | 7.2 | 3-35 | 120 | 55 | |
| JS-7.2×200 | 8.0" | 200 | 3-50 | ||||
| JS-7.2×250 | 10" | 250 | 4-65 | ||||
| JS-7.2×300 | 12" | 300 | 4-80 | ||||
| JS-7.6×350 | 14" | 350 | 7.6 | 4-90 | 120 | 55 | |
| JS-7.6×400 | 16" | 400 | 4-105 | ||||
| JS-7.6×450 | 18" | 450 | 4-110 | ||||
| JS-7.6×500 | 20" | 500 | 4-150 | ||||
| JS-7.6×530 | 20.9" | 530 | 4-160 | ||||
| JS-7.6×550 | 21.6" | 550 | 4-165 | ||||
| JS-9.0×400 | 16" | 400 | 9.0 | 8-105 | 175 | 79.4 | |
| JS-9.0×450 | 18" | 450 | 8-118 | ||||
| JS-9.0×500 | 20" | 500 | 8-150 | ||||
| JS-9.0×550 | 21.6" | 550 | 8-160 | ||||
| JS-9.0×600 | 23.6" | 600 | 8-170 | ||||
| JS-9.0×650 | 25.6" | 650 | 8-185 | ||||
| JS-9.0×720 | 28.3" | 720 | 10-195 | ||||
| JS-9.0×760 | 28.3" | 760 | 10-210 | ||||
| JS-9.0×800 | 31.5" | 800 | 10-230 | ||||
| JS-9.0×900 | 35.5" | 900 | 10-265 | ||||
| JS-9.0×1020 | 29.4" | 1020 | 10-300 | ||||
| JS-9.0×1200 | 47.2" | 1200 | 10-370 | ||||
| JS-12×650 | 26.5" | 650 | 12 | 14-185 | 250 | 114 | |
| JS-12×900 | 25.5" | 900 | 14-265 | ||||
